Cloudray 3DM580S User Manual

3DM580S USER MANUAL
www.cloudraymotor.com
1
1. Product Overview
Thank you for choosing Cloudray DM series digital step servo drive.
DM series stepper drive, which surpasses the performance of common analog stepper drive comprehensively
based on the new 32-bit DSP platform developed by TI, and adopting the micro-stepping technology and PID
current control algorithm design. The DM series stepper drives have the features of low noise, low vibration,
low heating and high-speed high torque output, it is suitable for most stepper motors by integrated with the
micro-stepping technology.
3DM580S type switch stepper drive is provided with the pulse train with S-shape acceleration/deceleration,
and triggers the motor start-stop only by normal switching value..
Power supply
24 – 50VDC
Output Current
Up to 5.6 amps
（
peak value
）
Current control
PID current control algorithm
Micro-stepping settings
DIP switch settings, 16 options
Speed range
Use the suitable motor
，
up to 3000rpm
Resonance suppression
Automatically calculate the resonance point and inhibit the IF vibration
Parameter adaption
Automatically detect the motor parameter when drive initialize, optimize
the controlling performance
Pulse mode
Direction & pulse, CW/CCW double pulse, A/B orthogonal pulse
Pulse filtering
2MHz digital signal filter
Neutral current
Automatically halved the current after the motor stops running
We hope that our products with excellent performance can help you to complete the sports control program
successfully.
Please read this technical manual before using the products.
2. Application Environment and Installation
2.1 Environmental requirement
Item
Cloudray 3DM580S
Installation environment
Avoid dust, oil and corrosive environment
