Cloudray 3DM580S User Manual

3DM580S USER MANUAL
www.cloudraymotor.com
7
4.1 The setting of current
Peak Current
SW1
SW2
SW3
SW4
备注
Default
off
off
off
off
Other Current can be
custom-made
2.5
on
off
off
off
2.9
off
on
off
off
3.2
on
on
off
off
3.6
off
off
on
off
4.0
on
off
on
off
4.5
off
on
on
off
4.9
on
on
on
off
5.3
off
off
off
on
5.7
on
off
off
on
6.2
off
on
off
on
6.4
on
on
off
on
6.9
off
off
on
on
7.3
on
off
on
on
7.7
off
on
on
on
8.0
on
on
on
on
DIP SW1, SW2, SW3, SW4 are used to set current which is output from drive to motor.
Generally, the current setting is the motor rated current. If your system has high request to the heating, please
decrease the current properly to lower the motor’s heating, but at the same time, the output torque will be
lower. If you don’t need the motor running continuous, you can increase the current to higher the torque. But
be minded that the current can not be 1.5times over than the rated current.
4.2 The setting of pulse per revolution
Stepping
count/revolu
tion
SW6
SW7
SW8
Remarks
Default
on
on
on
Other
Subdivision can
be
custom-made
6400
off
on
on
500
on
off
on
1000
off
off
on
2000
on
on
off
4000
off
on
off
5000
on
off
off
10000
off
off
off
DIP SW6, SW7, SW8 are used to set the speed when the motor is triggered. Built-in S-type acceleration and
deceleration.
When the switch is closed, the motor accelerates to the set speed.
When the switch is off, the motor decelerates and stops.
4.2 Motor direction selection
DIP SW5 is used to set the running direction of the motor under the initial pulse.
The “off” means that the motor direction is counterclockwise when inputting the initial pulse;
The “on” means that the motor direction is clockwise when inputting the initial pulse.
