DM422S USER MANUAL
www.cloudratmotor.com
1. Product Overview
Thank you for choosing Cloudray DM series digital stepper drive.
DM series stepper drive, which surpasses the performance of common analog stepper drive comprehensively
based on the new 32-bit DSP platform developed by TI, and adopting the micro-stepping technology and PID
current control algorithm design. The DM series stepper drives have the features of low noise, low vibration, low
heating and high-speed high torque output, it is suitable for most stepper motors by integrated with the
micro-stepping technology.
The DM 556S driver can select the running current and subdivision through the DIP switch. There are 16
subdivisions and 8 current selections. It has overvoltage, undervoltage and overcurrent protection. Its input and
output control signals are optically isolated.
Up to 2.2 amps（peak value）
PID current control algorithm
DIP switch settings, 16 options
Use the suitable motor，up to 3000rpm
Automatically calculate the resonance point and inhibit the IF vibration
Automatically detect the motor parameter when drive initialize, optimize
the controlling performance
Support direction & pulse, CW/CCW double pulse, A/B quadrature pulse
input
2MHz digital signal filter
The current is automatically halved after the motor stops running
We hope that our products with excellent performance can help you to complete the sports control program
successfully.
Please read this technical manual before using the products.
2. Application Environment and Installation
2.1 Environmental requirement
