Club Car Precedent 2016 Service Manual

15
GeneralInformation
BATTERYCHARGER:FORERIC
CHARGINGSYSTEM
CHARGERPOWERCONNECTIONFUSE
Thechargerreceptacleharnesshasanin-line,30-ampfuselocatednearthesolenoid.
CHARGERINTERLOCK
ExternalCharger:WhilethechargerDCcordispluggedintothevehicle,thevehiclecontrolcircuitislockedout,
preventingoperationofthevehicle,aswellasthepossibilityofconsequentdamagetothechargerandthevehicle.
OnboardCharger:WhilethechargerACcordispluggedintoanelectricaloutlet,thevehiclecontrolcircuitislocked
out,preventingoperationofthevehicle,aswellasthepossibilityofconsequentdamagetothechargerandthevehicle.
ACINPUTVOLTAGEDETECTION
Thehigh-frequencychargerautomaticallydetectstheACinputvoltageandwilloperateatfullpowerifthevoltageis
withinthe100to240VACrange.Thechargeralsowillfunctionoutsideofthatrangedownto85VACandupto270
VACalthoughchargingtimeswillbelonger.Outsideofthe85to270VACrange,thechargerwillnotoperate.
THERMALCUTBACK
Thechargeroperatesatfullpowerinambienttemperaturesbetween-40°F(-40°C)and104°F(40°C).Thecharger
alsowillfunctionoutsideofthatrangealthoughchargingtimeswillbelonger.
CHARGEINDICATORLIGHT
ExcelSystemvehicleswithERICChargingsystemfeatureadashmountedchargeindicatorlight(belowthesteering
column)thatservestwofunctions:1)Batterylowstateofchargewarning,and2)Chargingconrmation.Thecharge
indicatorlightiscontrolledbypin11ofthecontroller.
BatteryLowStateofChargeWarning
•Thelightcomesonandremainssolidwhenthebatterystateofchargefallsbelow20%.
•Thelightbeginsashingwhenthebatterystateofchargefallsbelow10%.
ChargingConrmation
•Thelightwillashthreetimesandthereversebuzzersimultaneouslywillsoundthreetimestoindicateabattery
chargingsessionhasbegun.SeefollowingNOTE.
NOTE:ThenumberofashesandbeepscanvarydependingontheBeepOptionsetting.SeeBeepOption,
Section11,Page11-8.
CHARGERSTATUSINDICATORS
Theindicatorlightsonthechargerprovidesinformationconcerningchargerstatus.
_
LIGHTSTATUSSTATUSEXPLANATION
Solidred
Chargererror.Resetchargerpower.SeeResettingPower–External
Chargeronpage15-14.
FlashingorangeChargerunabletocompletecharge.
TABLECONTINUEDONNEXTPAGE
Page15-42016PrecedentGolfCarMaintenanceandServiceManual

Club Car Precedent 2016 Specifications

General

Model	Precedent
Year	2016
Seating Capacity	2
Power Source	Electric or Gas
Frame Material	Aluminum
Overall Length	91.5 inches
Wheelbase	65.5 inches
Ground Clearance	4.5 inches
Battery Type	Lead-Acid
Motor Type	48V DC
Batteries	6 x 8V (Electric)
Charger	Onboard or Offboard (Electric models)
Brakes	Mechanical drum
Top Speed	19 mph (Electric)
Suspension	Leaf spring with hydraulic shocks
Tires	18 x 8.5-8
