Club Car Precedent 2016 Service Manual

19
NeutralLockoutLimitSwitchELECTRICALCOMPONENTS–SUBARUEX40
NEUTRALLOCKOUTLIMITSWITCH
SeeGeneralWarningsonpage1-2.
TESTINGTHENEUTRALLOCKOUTLIMITSWITCH
SeeTestProcedure10–NeutralLockoutLimitSwitch–Pedal-StartVehiclesOnlyonpage18-29.
NEUTRALLOCKOUTLIMITSWITCHREMOVAL
1.TurnthekeyswitchOFFandremovethekey.PlacetheForward/ReversehandleintheNEUTRALposition.
Chockthewheels.
2.Disconnectbatteryandsparkplugwire(s).SeeSide-PostBattery:DisconnectingtheBattery-Gasoline
Vehiclesonpage1-3.
SeeTop-PostBattery:DisconnectingtheBattery-GasolineVehiclesonpage1-4.
3.Disconnectthe3-wireconnectorfromtheneutrallockoutlimitswitch(1)locatedonthetransaxle.
4.Removetwonuts(3)andwashers(4)fromtheneutrallockoutlimitswitch(1)andslidethelimitswitchoffof
thescrews.
NEUTRALLOCKOUTLIMITSWITCHINSTALLATION
1.Installthelimitswitch(1)withwashers(4)andnuts(3)andtightento5in·lb(0.6N·m).MovetheForward/Reverse
handletomakesuretheswitchactuates.SeefollowingCAUTION.
CAUTION
•Donotovertightentheretainingnuts.Ifthenutsareovertightened,limitswitchescouldbedamaged.
2.Connectthe3-wireconnectortotheneutrallockoutlimitswitchlead.
3.Connectbatteryandsparkplugwire(s).SeeSide-PostBattery:ConnectingtheBattery-GasolineVehicles
onpage1-3.
SeeTop-PostBattery:ConnectingtheBattery-GasolineVehiclesonpage1-4.
4.Testdrivethevehicleinbothforwardandreverseforproperoperation.
Page19-222016PrecedentGolfCarMaintenanceandServiceManual

Club Car Precedent 2016 Specifications

General

Model	Precedent
Year	2016
Seating Capacity	2
Power Source	Electric or Gas
Frame Material	Aluminum
Overall Length	91.5 inches
Wheelbase	65.5 inches
Ground Clearance	4.5 inches
Battery Type	Lead-Acid
Motor Type	48V DC
Batteries	6 x 8V (Electric)
Charger	Onboard or Offboard (Electric models)
Brakes	Mechanical drum
Top Speed	19 mph (Electric)
Suspension	Leaf spring with hydraulic shocks
Tires	18 x 8.5-8
