Club Car Precedent 2016 Service Manual

16
Motor
MOTOR(MODELEJ8-4001A):ELECTRIC
VEHICLE
MOTOR
SeeGeneralWarningsonpage1-2.
MOTORREMOVAL
1.Disconnectthebatteriesanddischargethecontroller.SeeDisconnectingtheBatteries–ElectricVehicles,
Section1,Page1-5.
2.Disconnectwiresfromtheterminalsonthemotorusingtwowrenchestopreventpostsfromturning.Label
thewirestoensureproperreconnection.
3.Slightlyloosenallthelugnutsonbothrearwheels.
4.Placeoorjackundertransaxleandraiserearofvehicle(Figure16-1,Page16-4)thenplacejackstandsunder
framecrossmemberbetweenthespringmountandthesidestringer,justforwardofeachrearwheel.Lowerthe
vehicletoletthejackstandssupportthevehicle(Figure16-2,Page16-4).SeefollowingWARNING.
WARNING
•Liftonlyoneendofthevehicleatatime.Useasuitableliftingdevice(chainhoistorhydraulicoor
jack)with1000lb.(454kg)minimumliftingcapacity.Donotuseliftingdevicetoholdvehicleinraised
position.Useapprovedjackstandsofproperweightcapacitytosupportthevehicleandchock
thewheelsthatremainontheoor.Whennotperformingatestorserviceprocedurethatrequires
movementofthewheels,lockthebrakes.
729
Figure16-
1LiftVehiclewithFloorJack
682
Figure16-2VehicleSupportedonJackStands
5.Removebothrearwheels.
6.Removethenut,cupwasher,andbushingfromthebottomsideoftheshockabsorber.Compresstheshock
absorber(pushingupwards)tomoveitoutoftheway(Figure16-3,Page16-5).
7.Removethenutsandboltsmountingtherearleafspringstotheshackles.
8.Togaineasieraccesstothemotor,lowerthetransaxleaslowasitwillgo.Ifmoreroomisneeded,removethe
jackfrombeneaththetransaxleandallowthespringstorestontheoor(Figure16-3,Page16-5).
Page16-42016PrecedentGolfCarMaintenanceandServiceManual

Club Car Precedent 2016 Specifications

General

Model	Precedent
Year	2016
Seating Capacity	2
Power Source	Electric or Gas
Frame Material	Aluminum
Overall Length	91.5 inches
Wheelbase	65.5 inches
Ground Clearance	4.5 inches
Battery Type	Lead-Acid
Motor Type	48V DC
Batteries	6 x 8V (Electric)
Charger	Onboard or Offboard (Electric models)
Brakes	Mechanical drum
Top Speed	19 mph (Electric)
Suspension	Leaf spring with hydraulic shocks
Tires	18 x 8.5-8
