Page 6
INSTALLATION INSTRUCTIONS
1. Packaged in the hardware kit that you purchased with your PRO3+ is an
install manual that explains in detail how to Install your servo and throttle rod.
2. Your wireless receiver needs to be placed in a location where it will not
be exposed to constant water exposure. A battery compartment, rod box,
anything similar would be a good location.
Keep in mind that this location also needs to allow for the wires to be able
to reach the battery, servo, steering, etc. As an additional consideration, the
signal between your remote and receiver is designed to work within a ~30ft
(9.1m) range even inside of an enclosed location.
Once you nd a suitable location, use the mounting holes and appropriate
hardware to secure it.
3. The main power leads connect directly the 12V battery using the ring
connectors provided. Red to +ve terminal, Black to -ve terminal. The positive
wire includes a standard blade fuse.
4. The ACC+ Switched power should be connected to a +ve 12V switched power
source at the helm station. When the outboard engine is not in use, the
switched power should be powered down.
5. The servo wire from your receiver needs to be routed to the servo mounted
on your kicker motor.
NOTE: If you need an extension to your servo cable, visit trollmasters.
com and look for the Parts Shop link. There is a 10ft (3m) extension
available. To minimize the impact of EMI, take care to route and secure
servo cable as far away as practical from the spark plug wires.
