CMS 4000 - Specifications

15
Edition 2.0 2010/06
7. Specifications
Model
Specifications
CMS 4000
CMS 5000
Input data
Max. DC power
4500W
5200W
Max. DC voltage
550V
550V
PV voltage range MPPT
110V-530V
110V-530V
Max. input current
18A
20A
DC voltage ripple
<5%
<5%
Max. number of strings
4
4
Ground fault monitoring
yes
yes
Reverse polarity protection
short-circuit diode
short-circuit diode
Output data
Max. AC power
4400W
5000W
Nominal AC output
4000W
5000W
THD of AC current
<3%
<3%
Nominal AC voltage
230V
230V
Nominal AC frequency
50Hz
50Hz
Power factor
1
1
Short-circuit proofing
yes
yes
Efficiency
Max. efficiency
98.00%
98.00%
Euro ETA
97.50%
97.50%
Protection rating
IP/65
IP/65
Mechanical
Width/height/depth(mm)
457/368/195
457/368/195
Weight
20.7KG
20.7KG
