8
⑦
Please carefully read the above picture for setup, and the mistake of any number or option will
lead to the failure of the engraving machine, or even lead to accident when operating the machine.
◆Trial run and manual control test for the machine
①Check and confirm: whether the connection among computer→control box→engraving machine is
correct; whether the software installation and parameter setting are correct;
②First, do not electrify the control box, and turn the
hand wheel of three step motors by hand now, you
will feel that under the condition without electricity,
they may be easily turned by hand; Then, plug in
the electricity supply, and turn on the "POWER"
switch, three step motors will be self locked at this
time. Turn the hand wheel by hand again, you may
fell that it is Slightly tight than the moment without
electricity. This states that the machine can be
controlled now, and you can send out an order to
control it now.
③ Start up MACH3 software. If the "RESET" button at the bottom left corner is flashing, then click it
with mouse, and begin to operate when it is static and not flashing; (attention that for a part of the
machine types, you must first turn on the "POWER" switch of the control box, and not press the
"EMERGENCY STOP" button).
To Next Page
