CNC4PC C32 - 2 Specifications

C32 (Rev. 5) User Manual
___________________________________________________________________________
User’s Manual Page 2
 Buffered outputs.
 Status LEDs on all inputs and output connections.
 Works directly with popular CNC hardware and software.
 34 inputs and outputs on 2 ports.
PINS
PORT1
PORT2
TOTAL
INPUT
5
12
17
OUTPUT
13
4
17
TOTAL
18
16
34
2.0 SPECIFICATIONS
OPTOISOLATED DIGITAL INPUT SPECIFICATIONS
Numbers of inputs
18
On-state voltage range
2 to 5V DC
Maximum off-state voltage
0.8V
Typical signal delay
2.8uS
DIGITAL OUTPUT SPECIFICATIONS
Number of outputs
16
Maximum output voltage
(5V power supply voltage) +
0.5V
Typical output current
24mA
Maximum off-state voltage
0.44 V
Maximum supported frequency
4M
Typical signal delay
10 nS
Time of transition to high impedance state
120mS*
