7. Product specifications
Product Name CSH-2400W
Ports 24 100BASE-TX/10BASE-T Ports
Standards IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3x Flow Control for Full-Duplex Operation
Forwarding/Filtering Rate 14880 packets/second per port@10Mbps, max
148800 packets/second per port@100Mbps, max
Configuration Interface IE Web browser
Auto-MDI-X All TP ports support Auto-MDI/MDI-X Function
Reset Button Reload IP, User Name and Password to default value
LED Indicators One (1) for Power
One (1) per port for Link/ACT
One (1) per port for Full-Duplex or Collision
Environment Operating Temperature: -20° ~ 45° C (-4° ~ 113° F)
Storage Temperature: -40° ~ 80° C (-40° ~ 176° F)
Humidity: 10% ~ 90% Non-condensing
Power Supply Internal full range switching power supply
Input voltage: 100 ~ 240 +-10%V AC 50/60 Hz
Certifications CE, FCC
Dimensions 442 x 185 x 44 mm (17.40 x 7.28 x 1.73 inches)
FCC WARNING
This equipment has been tested and found to comply with the limits for a Class A computing device pursuant to Part 15 of FCC
Rules, which are designed to provide reasonable protection against electromagnetic interference in a commercial environment.
Changes or modifications to the equipment not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
CE MARK WARNING
This is a Class A product. In a domestic environment this product may cause radio interference in which case the user may be
required to take adequate measures.
