4 SMART FUNCTION SETTINGS
4.1 Start Smart Function
The Switch has a smart function that you can use to manage your local area network (LAN )
more effectively. You also can use the default setting to make the Switch operate as a dumb
switch.
If you want to use smart function, install the Switch as below:
．Use the “RS-232” connector to connect the Switch to a computer. Connect one (1) cable end
to the Switch, and connect the other end to the computer’s “COM1” or “COM2” port.
Note: If your Windows program doesn’t have a hyper terminal, you have to install it first.
．Power “ON” the Switch
．Execute the “HyperTerminal” program:
Start Menu Æ Application Program Æ Communication Æ Hyper Terminal
．Setup the connection content of Hyper Terminal:
※ In connection tag, select which “COM” port is used to connect PC and the Switch.
※ Then press the “SETUP” button, set “Bits per second” to 19200, “Data bits” to 8, “Parity”
to None, “Stop bits” to 1, “Flow control” to None.
．After finishing the setting-up action in Hyper Terminal window, press any key to continue. Now
the computer can connect to Switch and use the user interface menu to select control function.
Note: If you also had “Term95”, it could be easy to use as the following procedures:
(a). Execute the “Term95” program;
(b). Select the “Setting” / “Line” into the ”RS232 settings” menu;
(c). RS232 settings: set as the following and select “Ok”.
Item Setting
Port COM
Baud rate 19200
Data bits 8 bits
Parity None
Stop bits 1
Flow control NA
(d). Power “ON” the Switch.
