9 Product specifications
Model 24 ports 100BASE-TX with 2 ports 1000BASE-T Gigabit Switch
Standards ．10BASE-T IEEE802.3
．100BASE-TX IEEE802.3u
．1000BASE-T IEEE802.3ab
．Flow Control IEEE802.3x
Ports ．Twenty-four (24) 100BASE-TX
．Two (2) 1000BASE-T
Media support ．10BASE-T: Cat. 3, 4 or 5 TP
．1000BASE-T/100BASE-TX: Cat. 5 TP
Bandwidth ．1000BASE-T 2000/200/20Mbps
．100BASE-TX 200/100/20/10Mbps
Forwarding/Filtering Rate ．1488100 packets/second per port@1000Mbps max.
．148810 packets/second per port@100Mbps max.
．14881 packets/second per port@10Mbps max.
Latency ．2.6µsec@ 1000Mbps minimum
．11µsec@100Mbps minimum
．75µsec@10Mbps minimum
MAC Addresses ．Embedded 8K MAC address, Self-Learning
Buffer memory ．Embedded 512K Bytes packet buffer
Duplex Modes ．Auto-Negotiation
Crossover ．Auto-Crossover function for each port
LED Indicators ．One (1) for display PWR status
For port 1 to 24 (100/10Mbps ports):
．One (1) per port for display LINK/ACT status
10Mbps Yellow/100Mbps Green
．One (1) per port for display FD/COL status
For port 25, 26 (1000/100/10Mbps ports):
．One (1) per port for display speed 1000Mbps LINK/ACT status
．One (1) per port for display speed 100Mbps LINK/ACT status
．One (1) per port for display speed 10Mbps LINK/ACT status
．One (1) per port for display FD/COL status
Power Supply ．Full range Auto-Switching
．Input voltage: 100~240 +/-10%V AC/50~60Hz
Power Consumption ．18Watt maximum
Environment ．Operating temperature: 0~45°C(32~113°F)
．Storage temperature: -20~70°C(-4~158°F)
．Humidity: 10%~90% Non-Condensing
Certifications ．FCC Class A
．CE Mark
Dimensions ．440x205x44mm (17.32x8.07x1.73 inches)
23
