5.6 Flow Control Setting
+----------------------------------------------------------------------+
| Flow Control Setting |
+----------------------------------------------------------------------+
| 1: On 2: On 3: On 4: On |
| |
| 5: On 6: On 7: On 8: On |
| |
| 9: On 10: On 11: On 12: On |
| |
| 13: On 14: On 15: On 16: On |
| |
| 17: On 18: On 19: On 20: On |
| |
| 21: On 22: On 23: On 24: On |
| |
| 25: On 26: On Set All Port: --- |
+----------------------------------------------------------------------+
'-': Previous '+': Next ESC: Exit Enter: Change Setting
As an example, if you would like to set Flow Control mode, you can set as the following steps:
(a). Enter the “Flow Control Setting” menu;
(b). Select the ports you would like to change the flow control function;
(c). Change the ports mode to on or off;
(d). Finish the flow control setting as your wish.
16
