Each VLAN’s setting is the same as VLAN group #1 which is the default setting. As the
following menu shown:
+----------------------------------------------------------------------+
| VLAN Group #1 |
+----------------------------------------------------------------------+
| 1: On 2: On 3: On 4: On |
| |
| 5: On 6: On 7: On 8: On |
| |
| 9: On 10: On 11: On 12: On |
| |
| 13: On 14: On 15: On 16: On |
| |
| 17: On 18: On 19: On 20: On |
| |
| 21: On 22: On 23: On 24: On |
| |
| 25: On 26: On Set All Port: --- |
+----------------------------------------------------------------------+
'-': Previous '+': Next ESC: Exit Enter: Change Setting
You can modify VLAN groups setting as your need.
For an example, if you would like to set VLAN group #2, you can setup as the following steps:
(1). Enter the “VLAN Group #2” menu;
(2). Select the ports you would like to add or delete;
(3). Change the ports mode to on(add) or off(delete);
(4). Finish the VLAN group #2 as your wish.
15
