CO/Tech E0336WST4H4PR - Main Unit Interface and Controls; Main Unit Display Overview

ENGLISH
4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
Buttons and functions
Main unit
1. Relative humidity from sensor 1
2. Outdoor symbol for sensor 1.
We recommend that sensor 1
be located outdoors in order
for theweather station to
provide as correct aweather
forecast as possible.
3. Low battery indicator for
sensor 1
4. Temperature from sensor 1
5. Signal strength from sensor1.
Illuminates when measurement
data is received and when
scanning for asensor.
6. Indoor relative humidity
7. Indoor temperature
8. Indoor comfort indicator
9. Snooze indicator.
Flashes when thesnooze
function is active.
10. Time/set alarm time
11. Alarm indicator.
Lights when thealarm function
is activated and flashes when
thealarm sounds.
12. Low battery indicator, main unit
13. Weather forecast
14. Atmospheric pressure
