3. Assembly
3.1 Assembling the handle
1. Foldout thelock levers (9) and turn them anti-clockwise
afew turns to loosen them. Spreadtheupper handle’s(8)
ends slightly apart so thelock teeth don’t catch.
Nowfold out theupper handle to theextended position.
Screwthelock levers clockwise to tighten, and then fold
thelock levers (9) back in to their lockedpositions.
2. Loosenthelock knobs (13) by turning them anti-clockwise
afew turns. Now, fold out thelower handle to its upright
position so that thespacers’ lock tabs engage into their
cut-outs (see figure). Screwthelock knobs (13) clockwise
to tighten them securely.
3. Placethecable into thecable clip (5) then clip thecable clip
onto thelower handle.
4. Operating instructions
4.1 Battery
The battery sits under theclear dome battery
cover(2).
Removing the battery
1. Pressthelatch (16) to open thecover.
2. Pressthesafety key’s (15) spring tab to
releaseand remove it.
3. Pressthelatch (16) completely forward and
pullout thebattery.
3.2 Grass collector
1. Snaptogether thegrass collector’s upper and lower part making sure that all snap latches are secure.
Startfrom theback and work forward.
2. Screwtwo screws into theunderside of thecollector, near themouth.
3. Makesure that all thecollector’s parts are correctly assembled.
3.3 Attaching the grass collector
• Attach thecollector by opening and holding up thedischarge cover (11). Thenattach thecollector (10) to its
catches on themower and release thedischarge cover.
• Remove thecollector by lifting up thedischarge cover and then lifting thecollector up from its catches.
• The mower can even be used without thecollector if thedischarge cover is completely folded down in
theclosed position.
Inserting the battery
1. Pressthelatch (16) to open thecover.
2. Pressthesafety key’s (15) spring tab to releaseand remove it. Makesure that thesafety key does not find
it’s way into thebattery compartment.
3. Slidethebattery base into theguides and push down. Youwill first hear one click, when thebattery crosses
thelatch and another click when thelatch locks thebattery securely inplace.
