COBHAM FliteLine CVC-151 User Manual

CVC-151
VHF Communication System
Installation Manual
Section 2 – Installation
150-048100 Rev. H
Page 29
Table 2-1. CVC-151 Pin-outs
PIN
DESCRIPTION
PIN
DESCRIPTION
1
D-DATA
31
NOT USED
2
+28V IN
32
RESERVED
3
+28V IN
33
RESERVED
4
NOT USED
34
RESERVED
5
POWER RETURN
35
RESERVED
6
NOT USED
36
NOT USED
7
POWER RETURN
37
RESERVED
8
NOT USED
38
RESERVED
9
RESERVED
39
NOT USED
10
NOT USED
40
E429_DISABL ARINC
11
RESERVED
41
E429_DISABL ARINC
12
NOT USED
42
NOT USED
13
D-CLOCK
43
RESERVED
14
NOT USED
44
NOT USED
15
+28V IN
45
RS_232_RX
16
NOT USED
46
RS_232_TX
17
CDU GND
47
DISABLE COMP
18
NOT USED
48
8.33_ENABLE
19
GND
49
RESERVED
20
NOT USED
50
RESERVED
21
NOT USED
51
ARINC IN 2A (429)
22
NOT USED
52
RESERVED
23
RESERVED
53
RESERVED
24
NOT USED
54
SDI BIT 10
25
RESERVED
55
GRAY CODE IN 2B
26
D-ENAB
56
TRANSFER
27
NOT USED
57
NOT USED
28
+10V DC
58
NOT USED
29
NOT USED
59
NOT USED
30
POWER RETURN (429 SHIELD)
60
MIC IN (HI)
Continues.........
