COBHAM FliteLine CVC-151 User Manual

CVC-151
VHF Communication System
Installation Manual
Section 2 – Installation
150-048100 Rev. H
Page 30
Table 2-1. CVC-151 Pin-outs (cont’d)
PIN
DESCRIPTION
PIN
DESCRIPTION
61
NOT USED
84
ENABLE PS
62
COMM AUDIO OUT HI
85
NOT USED
63
NOT USED
86
INTERLOCK TX
64
RESERVED
87
NOT USED
65
NOT USED
88
COMM AUDIO OUT LO
66
ARINC IN 1B
89
NOT USED
67
GRAY CODE IN 1B
90
ARINC OUT B (429)
68
NOT USED
91
NOT USED
69
GND (AUDIO SHIELD)
92
ARINC IN 2B (429)
70
NOT USED
93
NOT USED
71
SBY/
ACT
94
NOT USED
72
NOT USED
95
SDI BIT 9
73
2 VOICE_PTT
96
NOT USED
74
NOT USED
97
GRAY CODE 1A
75
ARINC OUT A (429)
98
NOT USED
76
NOT USED
99
GRAY CODE IN 2A
77
SIDE TONE OUT LO
100
NOT USED
78
NOT USED
101
DISABLE SQUELCH
79
ARINC IN 1A (429)
102
NOT USED
80
MIC_LOW/
PTT
103
STRAP SIDETONE
81
NOT USED
104
NOT USED
82
GND
105
SIDETONE OUT HI
83
NOT USED
106
NOT USED
