Chapter 3: Service & maintenance
52 Maintenance
System LEDs
App installation and system settings
The AIS app is installed in the SAILOR 6004 Control Panel during
installation of the SAILOR 6280/6281 AIS System.
Figure 37: LEDs on the SAILOR 6282 AIS Transponder
LED Colour Description
Power Green Power on.
Rx Yellow Rx mode. Lights up when a message is received. Off
when no activity.
Tx Red Tx mode. Lights up when a message is transmitted.
Off when no activity.
Table 10: LEDs on the SAILOR 6282 AIS Transponder
