Field replacement procedure – SAILOR 1000 XTR Ka/GX-R2 RF pack
Doc. No.: 97-178838-C
3. Remove the BUC control cable, the BUC coax
cable, and the LNB coax cable
4. Remove the four screws. Remove the transceiver
unit. Gently slight if out
5. Remove the polarizer from old unit.
6. Mount the polarizer on the new unit. Make sure
to keep the O-ring in place. 1 Nm
7. Gently slight the transceiver unit back in. Press it
all in, and pull it back out 1 mm. (That’s to make
sure that the feed horn doesn’t push on the
polarizer)
To Next Page
