INSTALLATION MANUAL 4600 CAN/PLIP
8
J-22 positive/negative perimetric input: to be connected to the vehicle roof lamp. The system confi gures automatically
the input polarity 10 s after it has been armed. Make the functional test of the system after is has been confi gured.
J-23 Negative input for additional modules: to be used as a triggering input for the connection of compatible Cobra
modules.
J-24 Do not connect.
J-25 CDL lock negative output: low power control signal to lock central door locking. Activated by the Cobra remote
control , if provided (see electrical diagram F).
J-26 Positive input for CDL motor closing signal: to connect as indicated in the specifi c vehicle PLIP installation
sheet or in the product installation guide for PLIP applications available on the web under Application manuals.
MAKE CONNECTIONS AS FOR ELECTRIC DIAGRAMS
6. - ACTIVE FUNCTIONALITIES.
6.1 - Interior protection with ultrasonic volumetric sensor.
The system protects the vehicle interior with a volumetric ultrasonic sensor. Any attempt to get into the vehicle will be
detected and the alarm will trigger.
6.2 - Perimetric protection with door open warning diagnostic.
The alarm will trigger by opening any door, boot and bonnet. Should you have left any door opened while arming, the
system will signal it by 3 fl ashes of the direction lights and 3 audible signals (5 audible signals if the arming/disarming
audible signals function has been activated).
6.3 - Cable cutting protection (only for systems with back-up battery siren).
The alarm will trigger if the system is not power supplied (cutting of cables - battery disconnection) signalling the sabotage.
6.4 - Engine crank inhibition.
As soon as the system is armed the engine cranking is not possible anymore.
6.5 - Arming the system with the volumetric ultrasonic protection disabled .
This function allows to arm the system leaving temporarily disconnected the interior volumetric protection. The protection
must be disabled any time you leave somebody or an animal in the vehicle. If you want to leave any window opened
also disable the protection to avoid false alarms. All other protections remain active.
To disable the volumetric protection proceed as follow:
switch the engine off being sure that the ignition switch has been turned to the OFF position. Within 5 s press the
emergency panel pushbutton and keep it pressed until it will fl ash once to confi rm only the volumetric protection has
been disabled. By keeping the pushbutton pressed the system will confi rm with two fl ashes that only the additional sensor
input has been disabled, with three fl ashes for both of them disabled. The selected protection will remain disabled until
the system will be disarmed. It will be automatically restored at the next arming.
Note: on some vehicles the system automatically disables the volumetric protection if any windows is left opened.
Ask your installer if this functionality is provided by the system fi tted on your vehicle.
