INSTALLATION MANUAL 4600 CAN/PLIP
21
9.- FUNCTIONAL TEST.
During the fi rst 25 s after the system has been armed all protection functionalities can be tested without triggering an alarm.
Make the following tests during the 28 s inhibition time with the system armed:
open then close one by one all doors and boot - Check if the system is confi rming with three audible signal, each
door opening detection.
Check the proper functionality of the volumetric ultrasonic sensor - Make movements from the back seat, their
detection will be confi rmed by a LED fl ashing.
Note: don’t check the proper functionality of the volumetric ultrasonic sensor with the windows opened as many CAN
applications are automatically excluding this protection when the windows are left opened.
Open the bonnet then lock the vehicle with the remote control - While arming the system will indicate the bonnet
opening with 3 fl ashes of the direction lights and correspondingly with audible signals.This test is applicable only if the
signal is detected from the CAN network or for systems wired siren.
Try to start the engine - If the engine cranking wires have been connected the engine will not start. Warning: on some
vehicle by turning the ignition key ON the system will disarm (TP OK detection).
Check if the PIN emergency Code works properly - By correctly entering the PIN code the system disarms.
10. - CAN INDEX MANUAL SELECTION.
The technical support could ask you to manually select a different CAN INDEX of the brand which has been loaded in
the main unit. To select a different CAN application (CAN INDEX) proceed as follows:
as soon as the system is powered - in the disarming state - the emergency panel LED fl ashes quickly for 5 s, during
this time frame keep pressed the emergency panel pushbutton until it will go off then release it. The LED starts fl ashing
slowly a number of time corresponding to the already set CAN INDEX (example 3 fl ashes for CAN INDEX 3).
While the LED is fl ashing slowly, press briefl y the button of the emergency panel to switch to the next INDEX; each time
you press the button the INDEX increases and so on. By pressing again when the last index has been selected the
system will switch back to the fi rst one of the list. Wait for the LED of to confi rm the current INDEX selection.
Note1: the same CAN INDEX can be used for many vehicle models, check the CAN INDEX table available on the web.
Note2: there are four PLIP index available, check the vehicle specifi c PLIP installation sheet or the PLIP application
manual available on the web in the “Application Manuals” section.
11. - SELF LEARNING PROCEDURE REQUIRED TO REPLACE THE MAIN UNIT OR THE WIRELESS
SIREN REPLACEMENT.
The siren supplied in the kit is delivered already programmed to the main unit. Should you have the need to replace the
siren or the main unit it is required to perform the self learning procedure as follows:
IMPORTANT:don’t perform the procedure on two different vehicles parked closed each other. Their sirens could be
memorized in one main unit only.
