47
TECHNICAL DATA 5500
Crane rating ft.lbs 25.000
Standard outreach ft. 18’ 6”
Slewing angle CONTINUOS
Boom elevation (-5° +72°)
Lifting height from base of crane ft. 18’ 6”
Remote control PROPORTIONAL
Pump capacity hydraul. “H” (pto) GPM 3.2
Working pressure psi 2.500
Crane weight lbs 1.000 (H) - 1060 (E)
Slewing torque ft.lbs 2.500
WINCH SPECIFICATION 5500
Winch pull line lbs 2.700
Pull line speed H ft/min 33
24V ft/min 16 - 31
Rope diameter inch. 5/16”
Wire rope length ft. 100
Cable breaking strength lbs minimum 13.300
Technical data not binding
LOAD CAPACITIES COBRA 5500
Pict. 25
