46
10 TECHNICAL DATA - WINCH SPECIFICATIONS
SERIES 5500 STANDARD EQUIPMENT
- High speed winch with planetary gears reducer - Continuous rotation with worm-gear
- Negativ brake for winch - Remote control with connection and 10 m. - 33' ft. of cable
- Hydraulic or electric swivel coupling, for continuous or radio remote control
rotation - Proportional monofunction-multifunction hydraulic system
- Load limiting device - Solenoid valve with manual functions (only for emergency)
- Two hydraulic extensions - Stop-end system for winch (up and down)
TECHNICAL DATA 5500
Crane rating KNm 35
Standard outreach m 5.65
Slewing angle CONTINUOUS
Boom elevation (-5° +72°)
Lifting height from base of crane m 5.65
Remote control PROPORTIONAL
Pump capacity hydraul. “H” (pto) l/min 12
Working pressure bar 175
Crane weight Kg 480 (E) - 455 (H)
Slewing torque KNm 3.5
WINCH SPECIFICATION 5500
Winch pull line daN 1200
Pull line speed H m/min 10
24V m/min 5 - 9.5
Rope diameter mm8
Wire rope length m 30
Cable breaking strength Kg minimum 6050
Technical data not binding
LOAD CAPACITIES COBRA 5500
Pict. 24
