AV1/2 Input
TheCVBSportiscapableofacceptingsignalsfromstandardvideosources(e.g.,cable/satelliteboxes,DVD
players,VCRs,etc.)
ConnecttheVIDEOportwiththeyellowplugofthethesuppliedAVcable.1.
ConnecttheL/Rportwiththered&whiteplugofthesuppliedAVcabletoinputtheaudiosignal.2.
VGA Input
TheVGAportoftheTViscapable ofacceptinghigh-denitionsignalsfromcomputerswithaVGAoutput
jack.Whenusedasacomputermoniter,connecttheVGAjackandthePCAudioInjackwitha15-PinD-Sub
cableanda3.5mmstereoaudiocable.
HDMI1/2 Input
HDMI(HighDenitionMultimediaInterface)isanewtypeofconnectionthattransmitsdigitalaudioandvideo
signalssimultaneouslyoverasinglecable.AHDMIcableisrequiredfortheHDMIconnection.
TheseHDMIinputconnectorsarecapableofreceivingvideoatresolutionsupto1080p(1080-progressive).
ComponentInput
AVInput      S-VideoInput
NOTE:
Besuretohaveallnecessaryconnectionsproperlydonebeforeconnectthepowersupply.1.
WheninputtheAVsignal,refertothemanualoftheexternalsourcesaswell.2.
COMPONENT 1
AV1
Unit Side Panel
AV2
Cable Connections
COMPONENT 2
