3.1 Mounting
Use four screws and washers when mounting the amplier to the front rack rails. For mobile use, the amplier should also
be secured using the 19” mounting elements on the rear panel.
LINUS12C 3. INSTALLATION
3. INSTALLATION
76.00mm / 3.00“
465.50 mm / 18.33“
454,18 mm / 17.88“
LIMIT
SIGNAL
PROTECT
MUTE
SEL
ESC
UP
DOWN
L I N U S 1 2 C
1 2
3
4
STORE
88.00 mm / 3.46“
10.00 mm
/ 0.39“
7.00 mm / 0.28“
444.00 mm / 17.48“
483.50 mm / 19.00“
440,00 mm / 17.45 “
429,75 mm / 16.92“
