Coda LINUS12C - AC Mains and Input Specifications

30
LINUS12C 5. SPECIFICATION
AC mains input connector Neutrik 32 A powerCON®
AC mains voltage (high range)**
(dual voltage SMPS with automatic
voltage range selection)
180 V = Minimum
230 V = Nominal
265 V = Maximum
AC mains voltage (low range)**
(dual-voltage SMPS with automatic
voltage range selection)
90 V = Minimum
115 V = Nominal
132 V = Maximum
AC mains frequency 47 – 63 Hz
Power consumption*
(¼ power = 600 W @ 4Ω
to represent typical music signal)
Amplier in standby = 17.6 W
Amplier idle = 191 W
Amplier ¼ power = 3200 W
AC Mains
Input
Input sources Analog & AES/EBU
Analog input impedance
(balanced)
12 kΩ
Maximum input level
(analog dierential)
+18 dBu/6.15 Vrms
Input connections
4 x XLR3 Analog IN
1 x RJ45 LINET IN (8 x CH)
1 x RJ45 LINET LINK (8 x CH)
1 x RJ45 AUX
Supported digital input formats
(Internal SRC)
32 kHz / 44.1 kHz / 48 kHz / 88.2 kHz /
96 kHz / 176.4 kHz / 192 kHz
