Coda LINUS12C - Output, Thermal, and Physical Data

31
RMS output power*
(20 Hz - 20 kHz, THD < 0.01%)
(all channels driven)
1600 W @ 8 Ω
3000 W @ 4 Ω
4000 W @ 2.7 Ω
4100 W @ 2 Ω
Peak output power*
(20 Hz - 20 kHz)
(all channels driven)
3200 W pk @ 8 Ω
6000 W pk @ 4 Ω
5500 W pk @ 2.7 Ω
4800 W pk @ 2 Ω
Maximum output voltage* +/- 155 V pk
Maximum output current* +/- 52 A pk
Damping factor
(8 Ω load, 1 kHz and below)
2500
Minimum output load 2 Ω nom
Power output connections
2 x Neutrik NL4 speakON®
1 x Neutrik NL8 speakON®
LINUS12C 5. SPECIFICATION
Output
Operating temperature
+5º C to +55º C
41º F to 131º F
Thermal output
(BTU/h)
679.02 = Idle
2124 = 20%
4437 = 50%
8287 = 100%
Thermal output
(kWh)
0.199 = Idle
0.623 = 20%
1.300 = 50%
2.429 = 100%
Cooling
2 x thermally controlled fans.
Hot air expelled at rear.
Thermal
