Overview
Automatic Whip Antenna 3040 Installation Handbook 7
Figure 3: Front view of the antenna control connector
Table 1: Pinouts for the antenna control connector
Pin no. Description
A+12VDC
BEarth
CTune
D Scan
E Tune status indicator
F Not used
A
B
C
D
E
F
