Installing the antenna
12 Automatic Whip Antenna 3040 Installation Handbook
Figure 4: Mounting footprint
15 mm
96 mm
164 mm
96 mm
140 mm
NOTE
Allow 70 mm over the
cable connections and for
minimum bending radius
Connectors
70 mm
