Automatic Whip Antenna 3040 Installation Handbook 23
3 Specifications
General
Table 3: General specifications
Item Specification
Frequency range 2.5 to 30 MHz (2.4 m whip)
2 to 12 MHz (4 m NVIS)
DC operating range 10 to 15.5 V DC
12 V DC nominal
Power rating 125 W PEP, voice and data
Power
consumption
0.4 A, typical
< 0.8 A, maximum
Input impedance 50
VSWR
≤ 1.5:1, typical
Tuning speed 1 s average for a new frequency
< 150 ms from memory
Memory channels Unlimited
Connectors Antenna control: 6-way
RF: UHF socket
Cables Antenna control: Pre-assembled multicore cable available
in a a number of lengths (see page 27,
Accessories)
Coaxial: RG58 cable available in a number of
lengths (see page 27, Accessories)
