Installing the antenna
Automatic Whip Antenna 3040 Installation Handbook 19
1 Protect any cables passing through metal panels with
rubber grommets.
1 Tape the connectors on the antenna, and approximately
25 mm (1 in) of each cable, with two layers of self-
amalgamating PIB tape (Rotunda 2501) or EPR tape (3M
Scotch™ 23).
1 Cover the self-amalgamating tape with two layers of
high-quality electrical tape (3M Scotch™ 33+, or
similar) to minimise aging of the self-amalgamating tape.
1 Screw the fibreglass or stainless steel whip to the riser,
then screw the riser to the spring.
1 Screw the spring onto the antenna stud at the top of the
housing of the antenna tuner.
Table 2: 3040 to NGT connections
Codan part
number
Cable type From connector on
antenna tuner...
To lead from
RF unit...
08-05627-xxx Multicore,
6m (19ft)
6-way antenna control
08-01503-xxx 50 coaxial RG58,
6m (19ft)
RF
NOTE
These cables are available in a number of
lengths (see page 27, Accessories).
WARNING
Do not cut the control or coaxial cable. If
the cables are too long, coil the excess
neatly and secure it out of the way with
cable ties.
Do not bunch the control and coaxial
cables together.
