Antenna / LED / Programming Port
Mount the supplied antenna/receiver to a clear spot on the vehicle’s windshield that
will not block the driver’s vision. A good location is usually high on the windshield
near the rear view mirror. Be careful not to mount the antenna/receiver on any
metallicwindowlm,asthiswilleffectsystemrange.Routetheantenna/receiver
cable to the control module and plug into the antenna port.
Additional Ports
DBI Port - 4 Pin Data Bus Interface
The DBI port is used for external Flashlogic data immobilizer & door lock Interface
modules to communicate with the vehicle’s databus. When using the DBI port to
control Flashlogic modules please refer to the D2D (Data to Data) function list
availablepervehiclermwareonthetechservicewebsite.
FLCART Cartridge Port
This port is for installing the Flashlogic FLCART data immobilizer & door lock
interface cartridge used to communicate with the vehicle’s databus.
FLCART 4 Pin Programming Port
This 4 port is used for programming the Flashlogic FLCART interface cartridge via
the FLPROG Weblink Updater. Refer to the Flashlogic website for more details.
FLCART Harness Port
This port is for the harness included with the FLCART interface cartridge. Refer to the
Flashlogic website for more details.
