Code Alarm caSEC - Pin Main Harness; Pin Input; Output Harness; Pin AUX Output Harness; Pin Door Lock Output Harness

52017 Voxx Electronics Corporation. All rights reserved.
3 Pin Lock Output Harness
9 Pin Input / Output Harness
5 Pin Main Harness
4 Pin AUX Output Harness
1
WHITE/RED PARKING LIGHT INPUT
2
WHITE PARKING LIGHT OUTPUT
3
BLACKGROUND
4
BROWNSIREN OUTPUT ( + )
5
RED BATTE RY 12V ( + )
5 PIN MAIN
1
BLUE/WHITE INSTANT TRIGGER INPUT ( - )
2
GREEN DOOR TRIGGER INPUT ( - )
3
ORANGE GROUND WHEN ARMED OUTPUT ( - )
4
PURPLE DOOR TRIGGER INPUT ( + )
5
YELLOWIGNITION INPUT ( + )
6
RED/WHITETRUNK RELEASE OUTPUT ( - )
7
BROWN/BLACKHORN OUTPUT ( - )
8
VIOLET/BLACK AUX 1 ( - )
9
LT GREEN/BLACK FACTORY DISARM OUTPUT ( - )
9 PIN INPUT / OUTPUT
1
PINK/BLACK AUX 5 OUTPUT ( - )
2
ORANGE/BLACK AUX 4 OUTPUT ( - )
3
GRAY/BLACKAUX 3 OUTPUT ( - )
4
WHITE/BLACKAUX 2 OUTPUT ( - )
4 PIN AUX
OUTPUT
1
BLUE UNLOCK ( - )
2
OPEN
3
GREEN LOCK ( - )
3 PIN
LOCK
