8 VIOLET/BLACK AUX 1
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.
9 LT GREEN/BLACK FACTORY DISARM OUTPUT ( - )
This wire will supply a ( - ) 200mA pulse upon disarming the system. Locate the
factory perimeter alarm disarm wire from the key cylinder inside the drivers door.
  Verication: This wire registers ground if the key is turned to the unlock
position in the driver’s door cylinder.
Connect the LT GREEN/BLACK wire to the factory alarm disarm wire.
4 Pin AUX Output Harness
1 PINK/BLACK AUX 5
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.
2 ORANGE/BLACK AUX 4
This wire provides a ( - ) 200mA output capable of driving relays. For Control of
optional accessories (i.e. Power Window/Sunroof, etc.).
 Toactivaterefertothetransmitterbuttoncongurationchart.Pleaserefertothe
selectable options for timing.
