CB 1 Series
Administrator Guide
18 Cellular Retro Instructions
TELULAR SX-5E & CALLFINDER CX100FX2 GSM-4 TO GSM-5
Installation Instructions
Retrot Instructions Telular & CallFinder
We strongly advise reading these instruction before any work is started. In addition, the age of these
units is possible the actual wiring may have changed by others, therefore the wiring guides provided
are originals and here for your reference.
Some early 2002 designs: a total rebuild is more effective and easier to accomplish. Contact customer
service a rebuild kit.
Telular GSM Removal Instructions Specically
Current Installations: If you still have a Telular cellular F.C.T. (Fixed Cellular Termi-
nal), inside your CB1 NightCharge™ or CB1w (Solar), CB 4-u NightCharge™ or CB
4-u Solar enclosure, it is a hardwired internal harness. The wiring in the enclosure is
bundled; therefore removing two wires from the bundled group is very time consum-
ing. You may choose to reuse existing wiring, cutting and splicing the power wires is
acceptable, if doing so, use self-sealing splices.
Consideration: abandoning the original power wires will require you to identify the
harness and power panel in order to properly attach the new GSM-5 power wires.
Review the list below for the most common congurations.
Hint: Cellular power terminate on the same buss as the Battery.
Models involved in this Retro – Visual Refer document Attached
CB1 CB 4-u
NightCharge™ 2002, 2005, 20t10 NightCharge™ 2002, 2005, 2010
W Solar 2005, 2008, 2010 - 2013 Solar 2005, 2008, 2010 - 2013
