Code Blue CB1 Series - CB 1-S with AED, Public Address and IP Wireless

Code Blue
•
259 Hedcor Street
•
Holland, MI 49423 USA
•
800.205.7186
•
www.codeblue.com
GU-157-AApage 68 of 76
CB 1 Series
Administrator Guide
40 CB 1-s with AED, Public Address and IP Wireless
FILENAME
DFB PAS IPWIRELESS WIRING.VSD
PAGE
1 OF 1
DRAWN BY
MIKE ROSE
Toroidal Transformer
120 V AC @ 3.2 amps to
V AC 54./24./17.5/9.5
380V A
120V AC
DFB1 w / PAS-IP w/Optional Wireless
24VAC
75 watt Heating Element
120V AC
LED AREA Lite
LED Faceplate
light
Lighting
5 Amp
PAS Power Supply
1
LANLAN
LAN
PoE
PAS
Control
Aux ports
PAS
Audio
+ -+ -
Power & Battery
IP5000
in out
GRD
Surge Protector
Phone line
Aux 1
Strobe
PAS
Control
Aux Outputs
1 2 3
1
3
2
4
N.O.
N.C.
Aux
Inputs
PAS
Audio
Aux input
2
Acc Pwr
1
Chassis Ground
Battery
Accessory
Power
Aux 1 Strobe
Aux input 1
IA4100
in out
GRD
Surge Protector
Ethernet
Door Release Mech
Red / Blu: Door Mech
Org / Org: Phones Aux Output #2
Red / Blk: Power 12 V DC
Brn / Brn: Unused
Mag Door Sw
AED Door Release Circuit
Interconnect
Cable
Optional Battery for IP5000 and IA4100 is used incase of power failure
operations. Battery does not provide power for anything but the phone
PAS 1 Module
PAS1 G2
Amplifier
PAS1 360°
Speaker
Array
Optional IP Wireless / IP5000 Only
Secure Mesh™
Ethernet
24V AC
Input
12 V DC
output
Converter
24V AC to
12V DC @ 5A
AC to DC Converter
Product wiring diagram shown reasonably represents current offering and is intended to assist in component identication and service. Earlier product
production may have different components and wiring connections. Reference the model and serial number from the unit ID tag and contact
manufacturer to conrm replacement part version and availability.
