Code Blue ● 259 Hedcor Street ● Holland, MI ● 4923 USA ● 800.205.7186 ● www.codeblue.com Rev 6/2021 page 12 of 57 GU-164-A
Enclosure (Surface or Flush)
Faceplate / Circuit board with Integrated IP Color Camera
LS1000 faceplate tools needed for installation:
1. Drill and screws to mount unit to wall.
2. Code Blue Security bit and any 1/4” bit drive handle.
Basic Flush Mount Installation Instructions for use by Installers:
1. Remove six security screws with Code Blue security bit and any 1/4” bit driver tool.
2. Separate LS1000 from enclosure and set aside carefully. The flush mount enclosure will come with no mounting
holes. It can be mounted from the sides, top or bottom. Once your mounting needs have been determined, drill the
holes needed for your specific installation requirements into the flush mount back box.
3. Mark the mounting holes onto the mounting surface. In order to comply with the Americans with Disabilities Act
(ADA) of 1990, the speakerphone button(s) should be positioned between 34 and 48 inches from grade level.
(Consult an ADA specialist in your area to verify local and federal guidelines.)
4. Connect earth ground to the provided copper grounding lug using a minimum 14-gauge conductor.
5. Connect electrical and communications wiring using the wiring diagram below.
6. Follow all federal and local codes that apply.
7. Attach faceplate to enclosure using six security screws.
Basic Surface Mount Installation Instructions for user by Installers:
1. Remove six security screws with Code Blue security bit and any 1/4” bit driver tool.
2. Separate LS1000 from enclosure and set aside carefully.
3. Mark the mounting holes onto the mounting surface. In order to comply with the Americans with Disabilities Act
(ADA) of 1990, the speakerphone button(s) should be positioned between 34 and 48 inches from grade level.
(Consult an ADA specialist in your area to verify local and federal guidelines.)
4. Drill all marked holes.
