D014465 CR1400 CR1000 CR2300 CR2600 CR3600 CR44X5 CR8000 CR900FD CR6000 CR5000 T500 Client Version ICD
Page 32 of 106
© 2013-2016 The Code Corporation  12393 South Gateway Park Place Suite 600, Draper, UT 84020  (801) 495-2200  FAX (801) 495-0280
Reg
Setting Name
Default (Hex)
Comment
13
1D Barcode
Aggressiveness
0
0: Most Aggressive
1: Less Aggressive for poorly printed 1D barcodes
2: Least Aggressive for poorly printed 1D barcodes
#11: Less Aggressive for 1D barcodes with low module size (1X
near 1.0 pixel per module)
#12: Least Aggressive for 1D barcodes with low module size
(1X near 1.0 pixel per module)
14
Image Transform
0
0: No Transform
1: Mirror – Enables decoding of mirrored Data Matrix, QR, Han
Xin, and Aztec symbologies. Those symbologies must be
enabled.
Keywords: #Aztec, #DataMatrix, #HanXin, #QR
16
Data Matrix
Rectangular Symbology
1
0: Disabled
1: Enabled
Note: This register has no effect on a CR900FD without the
proper 2D barcode decoding license.
Keywords: #DataMatrix
19
Data Matrix Symbology
3
Binary Dip Switch
Bit
Controls
Value
0
Data Matrix Decoding
0: Disabled
1: Enabled
1
Inverse Data Matrix Decoding
0: Disabled
1: Enabled
2
Mirror Data Matrix Decoding
0: Disabled
1: Enabled
Note: This register has no effect on a CR900FD without the
proper 2D barcode decoding license.Keywords: #DataMatrix
1A
Straight 2 of 5
Symbology
0
0: Disabled
1: Enabled
Straight 2 of 5 (with 2 or 3 start/stop codes) Decoding.
Note: Straight 2 of 5 with 2 start/stop is also called IATA 2 of 5.
Straight 2 of 5 with 3 start/stop is also called Industrial 2 of 5.
CD12.3.0 supports Industrial 2 of 5. CD 13.1.4 supports IATA 2
of 5.
Keywords: #2Of5
