4/14/2016
D014465 CR1400 CR1000 CR2300 CR2600 CR3600 CR44X5 CR8000 CR900FD CR6000 CR5000 T500 Client Version ICD
Page 46 of 106
© 2013-2016 The Code Corporation
12393 South Gateway Park Place Suite 600, Draper, UT 84020
(801) 495-2200
FAX (801) 495-0280
Reg
Setting Name
Default (Hex)
Comment
4F
MSI Plessey Symbology
0
Binary Dip Switch with bits 1-3 comprising one value
Bit
Controls
Value
0
MSI Plessey
0: Disabled
1: Enabled
Bits 1-3
This is a value based
setting.
Calculate and compare
checksums of this type
and/or removal of the
checksum (See
examples below)
0: Disabled checksum
checking
1: One Byte Modulus 10
2: One Byte Modulus 10 &
One Byte Modulus 11
3: Two Bytes Modulus 10
4: reserved
5: One byte Modulus 10 then
strip
6: check modulus 10 & 11
then strip
7: check two modulus 10
then strip
5
UK Plessey
(original)
0: Disabled
1: Enabled
Examples: To decode MSI Plessey:
MSI Mod10: set 4F to 3 (hex)
MSI Mod11/10: set 4F to 5 (hex)
MSI Mod10/10: set 4F to 7 (hex)
MSI Mod10 with removal, set 4F to B (hex)
MSI Mod11/10 with removal: set 4F to D (hex)
MSI Mod10/10 with removal: set 4F to F (hex)
