8
D027166_02 User Manual
11.0 - Reader ID and Firmware Version
12.0 - CR950 Overall Dimensions
2.75"
(70 mm)
5.5"
(140 mm)
2.0"
(50 mm)
Note: Code will periodically release new firmware for CR950 readers. For information on latest firmware visit our website at
www.codecorp.com/codesupport.php.
Below is an example of reader parameter output:
<RD><RR SN=”0000000000” ID=”96919606” HR=”0x00” MD=”CR950” MT=”2A90” IS=”20161123:0831” /></RD>
where SN is the serial number, ID is the reader identifier, HR is hardware revision, MD is the model number, MT is the model type, and IS is
the reader information string
<RD><FW MJ=”1” MN=”4” BU=”1” OP=”” VS=”1.2.1” TY=”C010718” DV=”cd(16.1.6)” /></CP>
where MJ is the major version, MN is the minor version, BU is the build number, OP is the option version, VS is the firmware version, TY is the
firmware type, and DV is the decoder version.
To find out the Reader ID or Firmware version:
1. View the CR950 Configuration Guide located on at www.codecorp.com/files.php.
2. From the Reader/Modem Command Settings section, locate the “Get Reader Parameters”.
3. Open a text editor program (i.e., Notepad, Microsoft Word, etc.)
4. Scan the configuration barcode.
To Next Page
