COEF MP250 ZOOM - Channel and Digital Value Mapping

Pag. 10 http://www.coef.it - info@coef.it
SHUTTER / STROBE / DIMMER
0-5 SHUTTER closed
6-100 DIMMER from channel 9 value
101-110 DIMMER 0 > 100% Automatic 6 sec.
111-120 DIMMER 100% > 0 Automatic 6 sec.
121-126 DIMMER 0 > 100% slow Faster shut down
127-132 DIMMER 0 > 100% middle Faster shut down
133-138 DIMMER 0 > 100% fast Faster shut down
139-144 DIMMER 100% > 0 slow Faster open
145-150 DIMMER 100% > 0 middle Faster open
151-156 DIMMER 100% > 0 fast Faster open
157-162 Dimmer 0 > 100% > 0 slow
163-168 Dimmer 0 > 100% > 0 middle
169-174 Dimmer 0 > 100% > 0 fast
175-180 Strobe lamp from 1 to 6 random [reg. 0.0-0.5 sec.]
181-186 Strobe lamp from 1 to 6 random [reg. 0.6-1.5 sec.]
187-192 Strobe lamp from 1 to 6 random [reg. 1.6-2.5 sec.]
193-250 STROBE Speed adjustment
251-255 SHUTTER open
COLOR MODE 1
0 - 5 Neutral
6 - 15 Yellow
16 - 25 Blue
26 - 35 Magenta
36 - 45 Green light
46 - 55 Orange
56 - 65 Cyano
66 - 75 Pink
76 - 85 Red
86 - 95 Blu light
96 - 105 Green
106 - 115 Wood
116 - 125 White-Yellow
126 - 135 Yellow-Blue
136 - 145 Blue-Magenta
146 - 155 Green light-Orange
156 - 165 Orange-Cyano
166 - 175 Cyano-Pink
176 - 185 Red-Blue light
186 - 195 Blue light-Green
196 - 200 Random full-color (slow)
201 - 205 Random full-color (fast)
206 - 230 CW Rotation adjustment
231 - 255 CCW Rotation adjustment
COLOR MODE 2
0 - 5 Neutral
6 - 10 Yellow
11 - 15 Blue
16 - 20 Magenta
21 - 25 Green light
26 - 30 Orange
31 - 35 Cyano
36 - 40 Pink
41 - 45 Red
46 - 50 Blu light
51 - 55 Green
56 - 60 Wood
61 - 180 Positioning
181 - 185 Random fast
186 - 190 Random middle
191 - 195 Random slow
196 - 200 Random very slow
201 - 215 Random very fast
216 - 235 CW Rotation adjustment
236 - 255 CCW Rotation adjustment
SHUTTER / STROBE / DIMMER
0-5 SHUTTER closed
6-100 DIMMER Adjustment
101-110 DIMMER 0 > 100% Automatic 6 sec.
111-120 DIMMER 100% > 0 Automatic 6 sec.
121-126 DIMMER 0 > 100% slow Faster shut down
127-132 DIMMER 0 > 100% middle Faster shut down
133-138 DIMMER 0 > 100% fast Faster shut down
139-144 DIMMER 100% > 0 slow Faster open
145-150 DIMMER 100% > 0 middle Faster open
151-156 DIMMER 100% > 0 fast Faster open
157-162 Dimmer 0 > 100% > 0 slow
163-168 Dimmer 0 > 100% > 0 middle
169-174 Dimmer 0 > 100% > 0 fast
175-180 Strobe lamp from 1 to 6 random [reg. 0.0-0.5 sec.]
181-186 Strobe lamp from 1 to 6 random [reg. 0.6-1.5 sec.]
187-192 Strobe lamp from 1 to 6 random [reg. 1.6-2.5 sec.]
193-250 STROBE Speed adjustment
251-255 SHUTTER open
COLOR MODE 1
0 - 5 Neutral
6 - 15 Yellow
16 - 25 Blue
26 - 35 Magenta
36 - 45 Green light
46 - 55 Orange
56 - 65 Cyano
66 - 75 Pink
76 - 85 Red
86 - 95 Blu light
96 - 105 Green
106 - 115 Wood
116 - 125 White-Yellow
126 - 135 Yellow-Blue
136 - 145 Blue-Magenta
146 - 155 Green light-Orange
156 - 165 Orange-Cyano
166 - 175 Cyano-Pink
176 - 185 Red-Blue light
186 - 195 Blue light-Green
196 - 200 Random full-color (slow)
201 - 205 Random full-color (fast)
206 - 230 CW Rotation adjustment
231 - 255 CCW Rotation adjustment
COLOR MODE 2
0 - 5 Neutral
6 - 10 Yellow
11 - 15 Blue
16 - 20 Magenta
21 - 25 Green light
26 - 30 Orange
31 - 35 Cyano
36 - 40 Pink
41 - 45 Red
46 - 50 Blu light
51 - 55 Green
56 - 60 Wood
61 - 180 Positioning
181 - 185 Random fast
186 - 190 Random middle
191 - 195 Random slow
196 - 200 Random very slow
201 - 215 Random very fast
216 - 235 CW Rotation adjustment
236 - 255 CCW Rotation adjustment
5.0 CHANNELS AND DIGITAL VALUES
8 CHANNELS 9 CHANNELS
CH
1
2
MODE1
2
MODE2
