3.0 POWER SUPPLY CONNECTIONS
Supply the projector by connecting it as indicated in picture
Power supply: 100/120/200/230 V~ 50-60 Hz. Voltage and frequency as indicated on the rear of the projector.
Power absorbed: see table pag. 4
3.1 DMX 512 CONNECTIONS
Connect the projector to the control unit by means of a RG58 or RG59 coaxial cable supplied with 3 Pin XRL
Cannon plugs and connectors. Respect, according to the indications on the panel, the input and the output of the
DMX 512 signal.
