http://www.coef.it - info@coef.it Pag. 11
GOBOS
0 - 10 Neutral
1 1- 20 GOBO 1 chann.4 controls rotation
21 - 30 GOBO 2 chann.4 controls rotation
31 - 40 GOBO 3 chann.4 controls rotation
41 - 50 GOBO 4 chann.4 controls rotation
51 - 60 Reduction
61 - 70 GOBO 5 chann.4 controls rotation
71 - 80 GOBO 6 chann.4 controls rotation
81 - 90 GOBO 7 chann.4 controls rotation
91 - 100 GOBO 8 chann.4 controls rotation
101 - 110 GOBO 1 chann.4 controls position
111 - 120 GOBO 2 chann.4 controls position
121 - 130 GOBO 3 chann.4 controls position
131 - 140 GOBO 4 chann.4 controls position
141 - 150 GOBO 5 chann.4 controls position
151 - 160 GOBO 6 chann.4 controls position
161 - 170 GOBO 7 chann.4 controls position
171 - 180 GOBO 8 chann.4 controls position
181 - 193 GOBOS Fast random
194 - 205 GOBOS Slow random
206 - 230 CW Rotation adjustment
231 - 255 CCW Rotation adjustment
GOBOS ROTATION
0 - 5 STOP
6 - 255 From 0 to 540° GOBO positioning
6 - 130 CW Rotation adjustment of the GOBO
131 - 255 CCW Rotation adjustment of the GOBO
PAN MOVEMENT
PAN MOVEMENT FINE ADJUSTMENT
TILT MOVEMENT
TILT MOVEMENT FINE ADJUSTMENT
DIMMER
0 - 10 DIMMER CLOSED
11 - 250 DIMMER Adjustment
251 - 255 DIMMER OPEN
WARNING : position CHANNEL 1 at a value between 6 and 100,
in order to control DIMMER with this channel.
GOBOS
0 - 10 Neutral
11 - 20 GOBO 1 chann.4 controls rotation
21 - 30 GOBO 2 chann.4 controls rotation
31 - 40 GOBO 3 chann.4 controls rotation
41 - 50 GOBO 4 chann.4 controls rotation
51 - 60 Reduction
61 - 70 GOBO 5 chann.4 controls rotation
71 - 80 GOBO 6 chann.4 controls rotation
81 - 90 GOBO 7 chann.4 controls rotation
91 - 100 GOBO 8 chann.4 controls rotation
101 - 110 GOBO 1 chann.4 controls position
111 - 120 GOBO 2 chann.4 controls position
121 - 130 GOBO 3 chann.4 controls position
131 - 140 GOBO 4 chann.4 controls position
141 - 150 GOBO 5 chann.4 controls position
151 - 160 GOBO 6 chann.4 controls position
161 - 170 GOBO 7 chann.4 controls position
171 - 180 GOBO 8 chann.4 controls position
181 - 193 GOBOS Fast random
194 - 205 GOBOS Slow random
206 - 230 CW Rotation adjustment
231 - 255 CCW Rotation adjustment
GOBOS ROTATION
0 - 5 STOP
6 - 255 From 0 to 540° GOBO positioning
6 - 130 CW Rotation adjustment of the GOBO
131 - 255 CCW Rotation adjustment of the GOBO
PAN MOVEMENT
PAN MOVEMENT FINE ADJUSTMENT
TILT MOVEMENT
TILT MOVEMENT FINE ADJUSTMENT
8 CHANNELS 9 CHANNELS
CH
3
4
5
6
7
8
9
SPECIAL ACTION
When the lamp control via DMX (CDMX) and the RDMX function have been activated in the configuration menu, it’s possible,
by a combination of the channels values, to control the lamp switch ON/OFF or to allow the projector MASTER RESET.
Lamp ON via DMX:
CHANNEL 2 = value 0
CHANNEL 3 and CHANNEL 4 = value0>255>0
Lamp OFF via DMX:
CHANNEL 2 = value 255
CHANNEL 3 and CHANNEL 4 = value0>255>0
MASTER RESET:
CHANNEL 1 = value 0
CHANNEL 2 and CHANNEL 3 = value0>255>0
