17. The 3-core cable connections for 1 heater operation from a 230V~, 10A/13A supply are as
follows:
LIVE BROWN
NEUTRAL BLUE
EARTH GREEN/YELLOW
Important: Where a beverage machine is to be connected to a 13A UK domestic socket
outlet, a 3-core power cable capable of carrying a minimum current of 13A, Part No.
54416, must be used. This cable is fitted as standard.
