AETERNA CHANGE-GIVER COIN MECHANISM REL. 2.7
®
1.3. Parts description
1.3.1. Aeterna Change-Giver Coin Mechanism
With the Aeterna Executive, BDV Change-Giver Coin Mechanism, for electromechanical vending
machines too, are supplied both a connecting harness to the vending machine and a harness for
MDB peripherals.
fig. 3
1 = Connecting harness to MDB perpherals
2 = Connecting harness to the vending machine
3 = Validator/Separator group
4=Tube group
5 = Ejection group
Attention: the drawings of this manual have only an explanatory purpose and do not allow
any intervention in the Coin Mechanism. On this matter the manufacturer is not responsi-
ble for possible malfunction due to maintenance or repair carried out by unskilled person-
nel.
