Cognex 3D-A5000 Series User Manual

Operating Conditions
Be aware of the general operating conditions of a 3D-A5000 sensor:
Specification Description Notes
IP Rating IP65
Operating temperature range 0 - 40°C Accurate measurements in
trigger mode:22°C +/- 5°C
Storage Temperature -10°C to 60°C
Ambient Temperature 0°C to 40°C
Power Supply Requirements
+24VDC +/- 10%
144W (6.0A)with illumination on at maximum
intensity
15W (0.6A)with illumination off
Operating Current
Up to 6.0A depending on operation-mode
Maximum Humidity 85% non-condensing (maximum)
Shock (unit in a shipping padded
container)
3 Axis, 50 Gs (11ms half-sine pulse)
Vibration
Non-operating (unit does not acquire images while
under vibration): 3 Axis, 8 Gs (10-500 Hz for 30
minutes)
Accurate Measurements: 3 Axis, 2G RMS Sine
Sweep 10-200 Hz continuous
Trigger Inputs
1 opto-isolated acquisition trigger input
4V...24V (High); 0.0V...0.5V (Low)
Configurable as current sink (NPN) or current
source (PNP)
Discrete Outputs
3 opto-isolated outputs
Configurable as current sink (NPN) or current
source (PNP)
8
Cognex 3D-A5000 Sensors

Cognex 3D-A5000 Series Specifications
