DataMan Reader Imager Specifications
Specification DM474 Variant DM475 Variant
Image Sensor 1/1.8″ CMOS 2/3″ CMOS
Image Sensor Properties Diagonal 8.9 mm; 3.45 μm square pixels Diagonal 11.1 mm; 3.45 μm square pixels
Image Sensor
Resolution
2048 x 1536 2448 x 2048
Electronic Shutter Speed Min. exposure: 15 μs Max. exposure: 1000 μs with internal illumination/10000 μs with
external illumination
Max Acquisition Up to 55 Hz Up to 37 Hz
Algorithms and
Technologies
1DMax, 2DMax, Hotbars, PowerGrid
Lens Options Liquid lens 16 mm, 24 mm, 35mm Liquid lens 24mm, 35mm
20
Specifications
