Specifications
The following sections list general specifications for the reader.
Reader Specification
Specification DM474 Variant DM475 Variant
Weight 718 g
Power 24 VDC ±10%
Power Consumption
24 VDC ±10%, 1.5 A maximum
Supplied by LPS or NEC class 2 only
Trigger and Tune
Buttons
Yes; Quick Setup Intelligent Tuning
Laser Aimer Included
Discrete Inputs 2 fixed + (*) opto-isolated
Discrete Outputs 2 fixed + (*) opto-isolated
*Other I/O Points 2 user-configurable
Status Outputs Beeper, 5 multifunctional LEDs, 10 LED bar array, 360 degree indicator
Lighting Various controllable external light options
Communications Ethernet and Serial
Protocols RS-232, TCP/IP, PROFINET, EtherNet/IP(TM), SLMP, Modbus TCP, NTP, SFTP, FTP, MRS
Java Scripting enabled for custom protocols
Dimensions L: 184.8 mm, W: 67.8 mm, H: 77.8 mm
Operating
Temperature
0–57 °C (32–134.6 °F)
1
Storage Temperature -20–80 °C (-4–176 °F)
Operating and
Storage Humidity
< 95% non-condensing
Protection IP67 with cables
RoHS Certified Yes
Approvals (CE, UL,
FCC)
Yes
Vibration Spec 9 GRMS for 1.5hrs
Angle of Deflection -40° to +40°
Software Models QL, X
1
² In situations where the operating temperature exceeds 40 °C, an external heat sink isrequired.
19
